How do you use Hole Wizard in SolidWorks?

Hole Wizard Overview. You can use the Hole Wizard to create customized holes of various types. To create hole wizard holes, create a part and select a surface, click Hole Wizard (Features toolbar) or Insert > Features > Hole > Wizard, set the PropertyManager options, and click .

.

Subsequently, one may also ask, how do you change the Hole Wizard in Solidworks?

Creating Hole Wizard Standards

1. Click Options on the Standard toolbar, or click Tools > Options.
2. On the System Options tab, click Hole Wizard/Toolbox.
3. Browse to the Hole Wizard and Toolbox folder location.
4. Click Configure.
5. In the Toolbox configuration tool, set options on the Smart Fasteners page.

Additionally, where is the Hole Wizard in Solidworks? Hole Wizard Overview. You can use the Hole Wizard to create customized holes of various types. To create hole wizard holes, create a part and select a surface, click Hole Wizard (Features toolbar) or Insert > Features > Hole > Wizard, set the PropertyManager options, and click .

Regarding this, how do I draw a hole in Solidworks?

Creating a Simple Hole

1. Select a planar face on which to create the hole.
2. Click Simple Hole (Features toolbar) or Insert > Features > Hole > Simple.
3. In the PropertyManager, set the options.
4. Click OK to create the simple hole.
5. Right-click the hole feature in the model or the FeatureManager design tree, and select Edit Sketch.

How do you make a hole in Solidworks 2019?

Click the planar face approximately where you want to create the hole. Click Simple Hole or Hole Wizard (Features toolbar), or click Insert > Assembly Feature > Hole , then Simple or Wizard. Set the options as needed in the Hole PropertyManager or Hole Wizard Type PropertyManager.

Related Question Answers

How do you dimension a tapped hole in Solidworks?

Adding Hole Callouts in a Drawing

1. Click Hole Callout.
2. Click the edge of a hole, then click in the graphics area to place the hole callout.
3. Edit the callout in the Dimension PropertyManager.
4. Repeat steps 2 through 4 to insert additional hole callouts, then click .
